| Door Preparation |
Cross bore 2-1/8˝, Edge bore 1˝. |
| Backset: |
Includes one 4-Way deadbolt latch (2-3/8˝ to 2-3/4˝) and
two non-adjustable handleset latch with removable square corner faceplate (2-3/8˝ and 2-3/4˝). |
| Door Thickness: |
1-3/8˝ to 2˝. |
| Cylinder: |
Solid brass cylinder;
6-pin system and 5-pin ready Weiser keyway. |
| Deadbolt Latch Strike Plate: |
Standard 1-1/8˝ x 2-3/4˝ radius corner. |
| Deadlatch Strike Plate: |
Standard 1-3/4˝ x 2-1/4˝ full lip round corner. |
